CS Series CSC5
  • CS Series CSC5
  • CS Series CSC5
  • CS Series CSC5
  • CS Series CSC5
CS Series CSC5

Car Audio

CS Series CSC5

75W 5.25" Pair Coaxial Speakers

Powered Sub 80 46CSC54

The CS Series delivers remarkable performance and ultra-clean bass, utilizing a heavy-duty motor/magnet structure featuring EVC™ (Extended Voice Coil) technology not found in stock speakers. They use polypropylene cones with tough, ribbed, UV-treated surrounds for precise linear excursion and reliability.

CS Series CSC5

CS-Series 5-1/4-Inch Coaxial Speakers are an excellent upgrade from factory speakers. A significant upgrade from your factory sound, the stamped-steel framework supports a rigid polypropylene cone with EVC™ (Extended Voice Coil) technology for the best sonic quality. Using zero-protrusion PEI tweeters with neodymium magnets, you get the clarity you need without interfering with factory grilles. These CS speakers work best with 75 watts of recommended power. See below for more details.

  • Fits nearly every car made
  • Zero-protrusion tweeters to fit nearly any factory depth
  • Woofer EVC™ (Extended Voice Coil) tech assists with precise linear excursion
  • UV-treated poly-foam surround resists heat or direct sunlight
  • Large woofer magnet in a heavy-duty motor for ultra-clean bass
  • PEI-tweeter construction provides superb clarity
  • Neodymium tweeter magnets allow for increased volume in high frequencies
  • Steel mesh grilles included for speaker protection

Specifications

  • Speaker Design

    2 - way

  • Woofer Size | in [mm]

    5 1/4 [130]

  • Tweeter Size | in [mm]

    1/2 [13]

  • DC Resistance | ohm

    3.4

  • Peak Power | Watts

    225

  • Continuous Power | Watts, RMS

    75

  • Sensitivity [SPLo] | dB @ 1W, 1m

    90

  • Effective Frequency Range | Hz

    45-20k

  • Mounting Hole Diameter | in [mm]

    4 1/2 [115]

  • Top Mount Depth | in [mm]

    1/4 [7]

  • Bottom Mount Depth | in [mm]

    1 3/4 [45]

  • Tweeter Protrusion | in [mm]

    0

  • Grilles

    Yes

  • Tweeter Magnet Material

    Neodymium

  • Tweeter Dome Materia

    PEI [polyether imide

  • Tweeter Design

    Balanced dome

  • Woofer Cone Material

    Polypropylene

  • Woofer Surround Material

    Polyester foam

Available from leading retailers throughout New Zealand.

Find a New Zealand Kicker stockist!

 Where to buy
