CS Series CSC46

Car Audio

CS Series CSC46

50W 4x6" Pair Coaxial Speakers

Powered Sub 80 46CSC464

The CS Series delivers remarkable performance and ultra-clean bass, utilizing a heavy-duty motor/magnet structure featuring EVC™ (Extended Voice Coil) technology not found in stock speakers. They use polypropylene cones with tough, ribbed, UV-treated surrounds for precise linear excursion and reliability.

CS Series CSC46

CS-Series 4x6-inch Coaxial Speakers give you the quality you want, with the factory fit you need. The CS-Series design features near-zero tweeter protrusion, so your speakers fit perfectly behind factory grilles. This simple, drop-in solution delivers acclaimed KICKER performance with a stamped-steel framework, rigid polypropylene cone and EVC™ (Extended Voice Coil) technology. You get superb clarity, durability and volume – now and way down the road!These CS speakers work best with 50 watts of recommended power.

  • Fits nearly every car made
  • Zero-protrusion tweeters to fit nearly any factory depth
  • Woofer EVC™ (Extended Voice Coil) tech assists with precise linear excursion
  • UV-treated poly-foam surround resists heat or direct sunlight
  • Large woofer magnet in a heavy-duty motor for ultra-clean bass
  • PEI-tweeter construction provides superb clarity
  • Neodymium tweeter magnets allow for increased volume in high frequencies

Specifications

  • Speaker Design

    2 - way

  • Woofer Size | in [mm]

    4x6 [100x160]

  • Tweeter Size | in [mm]

    1/2 [13]

  • DC Resistance | ohm

    3.3

  • Peak Power | Watts

    150

  • Continuous Power | Watts, RMS

    50

  • Sensitivity [SPLo] | dB @ 1W, 1m

    88

  • Effective Frequency Range | Hz

    50-20k

  • Mounting Hole Diameter | in [mm]

    4 x 6 [101x152]

  • Top Mount Depth | in [mm]

    5/16 [7]

  • Bottom Mount Depth | in [mm]

    1 11/16 [43]

  • Tweeter Protrusion | in [mm]

    0

  • Grilles

    No

  • Tweeter Magnet Material

    Neodymium

  • Tweeter Dome Materia

    PEI [polyether imide

  • Tweeter Design

    Balanced dome

  • Woofer Cone Material

    Polypropylene

  • Woofer Surround Material

    Polyester foam
